050-1900 8mm Single Rotary Latch

TriMark's newest innovations in rotary latches, this product features a robust modular design that offers extensive actuation locations and options providing application flexibility in a compact design. Designed for medium to heavy-duty applications for on- or off-highway personnel, compartment door and door hold-open applications; this single rotor latch is available in both FMVSS 206 and non FMVSS 206 configurations. Other product details include:

  • Modular case construction is preconfigured with multiple actuation points on the front case allowing top/bottom actuation including stacked actuators as well as combinations of actuation points providing the most configurable rotary latch ever designed
  • It's compact size and shape allows maximum use of door space and minimizes visibility issues without compromising strength and robustness
  • Rotor provides for vertical clearance of strike allowing for door sag, misalignment and ease of installation
  • Two position rotor versions for personnel door and single position versions available for compartment and door hold-open applications

System kits are available and include handles, latches, accessories and keyless entry e-ASK systems to provide a comprehensive electro-mechanical access solution.


050-1100 Family - 8mm Single Rotor Latch

This new automotive style single rotor latch is designed for medium to heavy-duty applications for on or off-highway entrance doors, compartments and access panels. Product details include:

  • Compact size and shape allows for maximum use of door space and minimizes visibility issues
  • Dual position rotary latching function provides for vertical clearance of strike for door sag, misalignment and ease of installation
  • Modular case design provides for multiple latch actuation direction and locations for application flexibility
  • Use with 8mm diameter hoop strike

System kits are available and include handles, latches and accessories to provide a comprehensive access solution.


030-1860 Flush Mounted Paddle/Handle With Inside Lock Knob

This new flush mounted paddle handle family is a redesign of our popular 030-0850/0860/0875 Flush Mounted Paddle Handle product line and is designed for medium to heavy-duty on-highway vehicle entrance and compartment doors. Offering a clean, modernized style, they can be used in FMVSS 206 applications, are power lockable and feature 4 point pivot plate and lock cam actuation. Other product details include:

  • Easy to install, the separated bezel sandwiches the housing in the door skin (.083"-.127"/2.1-3.2mm) eliminating the need to maneuver the large pivot plates through the front side of the door cut-out
  • Installs into current 030-0850/030-0860/030-0875 cutouts
  • Molded rubber housing gasket (included) and "O rings" on axles provide for improved water infiltration
  • The 030-1875 features a free-float paddle in the locked position
  • The KeyOne Plus locking system allows the operation of multiple onboard locking hardware with a single key (030-1850/030-1875)
  • Available in a variety of finishes including black powder coated, high quality buffed chrome (CNNC) or a combination of black/chrome finish

System kits are available and include handles, latches, accessories and keyless entry e-ASK systems to provide a comprehensive electro-mechanical access solution.


030-2650 Motor Home Entrance Door Hardware-Rotary

Designed for RV motor home and fifth wheel trailer entrance doors and is a redesign of our 030-1000/030-1050 Motor Home Entrance Door Hardware. It features easy installation with through sandwich mounting, a reliable direct release rotary latch and is compliant to FMVSS 206 and has an optional built-in dead bolt for additional security that can be power lockable. Other product details include:

  • Low profile inside release (.940") to allow for close-fitting screen doors
  • Paddle is rigid when locked
  • Automotive styling with comfortable finger access
  • Inside assist with open bail for easy closing
  • Can be keyed to match other TriMark door products with KeyOne Plus for a single-key system

System kits are available and include handles, latches, rods, brackets and power lock actuators to provide a comprehensive electro-mechanical access solution.


540-0125 e-PAD Keypad With Relays

This stand alone keypad provides cost-effective and simple power door lock/unlock and unlatch control. The keypad, with on-board relays, provides increased security and convenience to minimize system and installation cost. Demanding users in the travel trailer, tool box, utility truck and low end motorized RV market will appreciate the high-end functionality at a value price. Other product details include:

  • Keypad can be mounted horizontally or vertically
  • User friendly keypad provides audible and touch feedback
  • Rugged and durable construction is compliant to on-road environmental requirements

System kits are available and include handles, latches, power lock actuators and electronic accessories including custom wiring harnesses, relays, switches, door contacts, actuators and mounting hardware to provide a comprehensive electro-mechanical access solution.


050-1600 TriGuard Slimline Heavy-Duty Latch

This slimline heavy-duty single rotor latch is designed for medium to heavy-duty vehicle entrance and rear door applications. It features a proven single rotor latch design, high strength 8 gauge (4.2mm) front mounting plate and robust straddle mount release lever. Other product details include:

  • The slim design mounts into 2.00" (50.8mm) doors and retrofits competitive single rotor wedge style rotary latches
  • Optional striker module provides rotor/cam assist to heavy doors, hinges and compensates for door sag
  • Custom configured release levers provide for application flexibility
  • Can be used on retrofit or new surface mount vehicle construction

System kits are available and include handles, latches and accessories to provide a comprehensive access solution.


050-0275 Slimline Cargo Latch

This compact single rotor latch is designed for light duty applications for on-road utility cargo doors. The case design allows the latch to be mounted closer to the door top and bottom edge for non-protruding striker details. Other product details include:

  • Compact size provides for more head clearance in a cargo door application
  • Allows for use with a hoop type striker
  • Available handed versions provide for 2-point remote applications

System kits are available and include handles, latches and accessories to provide a comprehensive access solution.


080-0400 CompOne Compression Lock

TriMark’s 080-0400 CompOne Compression Lock combines the compactness of a cam lock with smooth and secure pull-in functionality. Featuring 5mm of compression with a 180° turn of the key, this robust lock is intended for gasketed doors, is fully adjustable, water resistant and easy to install. Other product features include:

  • The KeyOne Plus locking system allows the operation of multiple onboard locking hardware with a single key or the option to key differently
  • Wide variety of accessories including cams, finger pulls and mounting hardware

System kits are available and include handles, latches and accessories to provide a comprehensive access solution.


060-1650 Motor Home Entrance Door Hardware

Designed for motor home and fifth wheel trailer entrance doors and is a redesign of our 060-0650 Motor Home Entrance Door Hardware. It features easy installation with through sandwich mounting, a low profile plunger style latch which is compliant to FMVSS 206, a built-in deadbolt for additional security and is power lockable. Other product details include:

  • Universal applications -- either right or left handed
  • Can be keyed to match other TriMark RV door products with KeyOne Plus for a single-key system
  • The inside release is low profile (.940") to allow for close fitting screen doors
  • Retrofits and installs in same door cutout as current 060-0650 Motor Home Entrance Door Hardware

System kits are available and include handles, latches, rods, brackets and power lock actuators to provide a comprehensive electro-mechanical access solution.


020-0850 e-LOCKING Pull Handle

TriMark’s NEW 020-0850 e-LOCKING Pull Handle for off-road applications allows power locking/unlocking via a switch, remote RF FOB transmitter or keypad. Based on the proven 020-0800, this robust pull handle brings automotive function and convenience to your cabs and enclosures. Other product details include:

  • Full gloved hand clearance and gas-assist molded handle provide ergonomic comfort and ease of operation especially in high door seal load applications
  • Provides the ability to remotely lock the exterior pull handle ?(Note: handle is rigid when locked)
  • Glass mounting with only 2 holes
  • KeyOne Plus lock cylinder can be keyed alike with most single and reversible key systems

System kits are available and include handles, latches, accessories and keyless entry e-ASK systems to provide a comprehensive electro-mechanical access solution.


020-0750 Flush Mount Pull Handle - Locked Rigid

This Flush Mount Pull Handle was specifically designed for compartment and entrance doors for off-highway vehicles. It offers ergonomic function and styling, is adaptable for power door lock actuation and has a "locked-rigid" handle when locked. Other product details include:

  • KeyOne Plus lock cylinder can be keyed alike with most single and reversible key systems
  • Housing flange and internal gaskets provided for resistance to water and dirt infiltration
  • Easy installation with (2) M6 nuts

System kits are available and include handles, latches, accessories and keyless entry e-ASK systems to provide a comprehensive electro-mechanical access solution.


050-0850 TriGuard Heavy Duty Latch Module with Slam Cam Option

This heavy-duty latch module is designed for medium to heavy-duty vehicle entrance and rear door applications. It features a proven single rotor latch design and high strength 8 gauge (4.2mm) front mounting plate with flange mounting. Other product details include:

  • Latch/striker module provides rotor/cam assist to heavy doors, hinges and compensates for door sag
  • Custom configured release levers provide for application flexibility
  • Can be used on retrofit or new surface mount vehicle construction

System kits are available and include handles, latches and accessories to provide a comprehensive access solution.




610-0100 Ignition Switch

TriMark’s Ignition Switches satisfy the toughest customers in the roughest environments with superior performance and reliability. Further enhancement is now available by offering a heavy duty ignition switch for on or off-highway applications with KeyOne Plus modular locking system providing “One Key – One Vehicle” convenience. Other product details include:

  • Standard positions/functions: Accessory, Off, On (Ignition/Accessory) and Start
  • Rugged and durable construction is environmentally sealed for long life
  • Contact rating: 50 Amp @12 VDC continuous (battery)
  • Standard 22mm mounting hole, retrofits with other standard panel mount ignition switches

System kits are available and include handles, latches and accessories to provide a comprehensive access solution.


040-1400 Push Button Center Control

This new product is a redesign of our popular 040-0400 Push Button Center Control for lift gates, access panels, compartment and baggage doors. It features KeyOne Plus keying in a push button actuation and a 2-point bellcrank linkage. Other product details include:

  • The KeyOne Plus locking system allows the operation of multiple onboard locking hardware with a single key or the option to key differently
  • Bypass lock mechanism allows push button to free-travel when locked for extra security

System kits are available and include handles, latches and accessories to provide a comprehensive access solution.


060-1300 Flush Mount Security Lock

This new product is a redesign of our 060-0300 Flush Mount Security Lock for recreational vehicle entrance doors including motor homes and travel trailers. Providing additional security in a remote mounted lock, it features true deadbolt functioning and is adaptable to power lock actuation. Other product details include:

  • The KeyOne Plus locking system allows the operation of multiple onboard locking hardware with a single key or the option to key differently
  • Easy to install, the universal design is non-handed and the gasket is pre-applied

System kits are available and include handles, latches and accessories to provide a comprehensive access solution.


020-1100 Remote Pull Handle

This flush mounted pull handle is designed specifically for entrance doors on RV and specialty vehicles that require remote actuation. Offering automotive styling, it provides greater ease of operation (ergonomics) than conventional paddle handles and can be used in FMVSS 206 applications. Other product details include:

  • Remote pivot and lock cam actuation
  • The KeyOne Plus locking system allows the operation of multiple onboard locking hardware with a single key
  • Available in a variety of finishes including black powder coated, high quality buffed chrome or a combination of black/chrome finish

System kits are available and include handles, latches and accessories to provide a comprehensive access solution.


030-1200 Round Paddle Handle

This new 030-1200 Round Paddle Handle was designed for use on personnel and compartment doors for light to medium duty on or off-road applications. Offering compact size for a cost effective price, this ergonomic handle brings a modern look and function to your cabs and enclosures.  The design provides for ease of operation by keying alike with other TriMark products with the KeyOne Plus lock. Other product benefits include:

  • Can be used in a direct latch release application or in conjunction with a bell crank for single remote actuation
  • Lightweight engineered plastic materials withstands corrosion and UV exposure
  • Available with a conventional paddle or open bail style handle for maximum leverage
  • Easy installation with (4) M6 high performance thread forming fasteners (included), mounting bracket is also available

System kits are available that include handles, latches and accessories to provide a comprehensive access solution.


030-2000 Two-Point Free Float Baggage Lock

This paddle handle was specifically designed for baggage and compartment doors for recreational vehicles including motor homes and travel trailers. It offers ergonomic function and styling, is adaptable for power door lock actuation and has a “free-floating” handle when locked. Other product details include:

  • Handle can be keyed to match other TriMark RV door products with KeyOne Plus for a single-key system or provided non-locking
  • Housing flange and internal gaskets provided for resistance to water and dirt infiltration
  • Supplied painted in a low gloss black finish, the product can be easily painted over to match body colors.
  • Two-point functionality works with TriMark rotary or plunger latches in doors 1.25” and thicker
  • Handle is easy to install with (3) 1 / 4 –20 UNC thread forming screws and mounting bracket (sold separately).Optional mounting bracket allows the power actuator to mount to the handle for ease of installation

System kits are available and include handles, latches, rods, brackets and power lock actuators to provide a comprehensive electro-mechanical access solution


020-0900 Remote Inside Release

This product was specifically designed for off-highway vehicle applications including agricultural and construction equipment that require a remote inside release. The robust construction is incorporated into round tubing for support for the opening and closing functions of the door and provides for greater ease of operation (ergonomics) over direct releases. Other product details include:

  • Available in 25mm or 32mm steel tubing diameters, painted black or sold as an inside release sub-assembly for installation into your door tube
  • Easy to install

System kits are available and include handles, latches and accessories to provide a comprehensive access solution.


050-1200 Single Rotor Panel Latch

This product is designed for light to medium duty compartment doors, access panels and hoods for off-highway vehicle applications. The single rotor latch offers robust construction and compact size for a very cost effective price. Other product details include:

  • Single position rotary latching function
  • Dual plane mounting flexibility
  • Direct tool operated or remote actuation

System kits are available and include handles, latches and power lock actuators to provide a comprehensive access solution.


030-1400 Paddle Handle

This flush mounted paddle is a redesign of our 030-0400 paddle handle for entrance doors on RV and specialty vehicles. Containing the same proven mechanical details as previous with a modernized look, it can be used in FMVSS 206 applications. Other product details include:

  • Remote pivot plate and lock cam actuation
  • The KeyOne Plus locking system allows the operation of multiple onboard locking hardware with a single key
  • Available in a variety of finishes including black powder coated, high quality buffed chrome or a combination of black/chrome finish

System kits are available and include handles, latches and accessories to provide a comprehensive access solution.


540-0200 Lighted Grab Handle with Keypad (e-GRAB)

This new product incorporates TriMark's e-ASK keypad into a stylish entry assist handle combination for RV coaches, motor homes and travel trailers. Offering increased end user convenience with high end look and feel, the grab handle provides keyless entry, security, and convenience through a keypad electronics interface. Other product details include:

  • Lighted keypad and handle rod for more effective night time usage
  • Optional door bell feature
  • High quality polished chrome plating is durable and stylish
  • Integrated product allows for easy installation

System kits are available and include handles, latches, remote transmitter FOB's and power lock actuators to provide a comprehensive access solution.


060-1200 RV Screen Door Latch

This product is designed to secure the screen door on recreeational vehicle entrance doors including motor homes and travel trailers. It features sturdy aluminum die cast construction and a low profile design that works with a variety of doors. Other product details include:

  • Dual function -- latch secures the screen door to the exterior door as well as the door jamb
  • Door strike and keepers are included for a total system solution


030-2300 Wedge Paddle Handle

This flush mounted paddle handle is designed specifically for medium to heavy-duty off-highway vehicle entrance doors that require remote actuation. It is retrofitable with similar excavator paddle handles and offers robust construction for a very cost effective price. Other product details include:

  • The KeyOne Plus locking system allows the operation of multiple onboard locking hardware with a single key
  • Choice of locking function; locked rigid within the paddle or remote free-float locking to connect with latch/linkage

System kits are available and include handles, latches and accessories to provide a comprehensive access solution.


200-0200 Cabinet Hinge

The TriMark 200-0200 Cabinet Hinge is a concealed hinge that surface mounts for ease of installation and totally hidden applications. The concealed hinge action has a rotational axis outside of the physical door (up and out) and provides for flush doors when closed. Other product details include:

  • The hinge is spring biased and is offered in 2 levels of loading with a heavy duty version that also incorporates a dampener that provides a soft-closing action
  • Alternative mounting patterns

System kits are available and include handles, latches and accessories to provide a comprehensive access solution.




020-0870 Power Locking Pull Handle With Capacitive Sensor - PKE

TriMark's new 020-0870 Power Locking Pull Handle for off-road applications features integrated capacitive sensor, PKE circuit board and power lock/unlocking motor drive. This innovative and robust pull handle allows use with TriMark's third generation of Remote Keyless Entry not only brings expanded vehicle function, convenience and security to the end consumer, it also adds value to the Original Equipment Manufacturer (OEM) by incorporating the Passive Keyless Entry (PKE), immobilization and keyless start into a single package.

Passive Keyless Entry (PKE) provides for "hands free" unlocking:

  • When the users hand enters the field under the handle portion, the system wakes up
  • This activity energizes the exterior antenna, FOB(s) in range will respond with their serial numbers contained in a data packet
  • If the FOB(s) respond with serial numbers that match an authorized list, the control module will pulse the unlock motor for 1/2 second to unlock the handle


100-5020 TriGuard Heavy Duty Door Module - V2

This heavy duty, pre-engineered door module was updated to provide expanded functionality. Providing automotive-like functionality in a low profile, easy to install one-piece module, it is now available with a rotating lever exterior handle and a second remote latch. Featuring TriMark's 050-1600 Heavy Duty Latch, it allows power locking and is compliant to FMVSS 206 (ECE R11) strength requirements. Other product details include:

  • Heavy duty modular construction is received fully assembled and tested - reduces door assembly as much as 50% to 70% - improving vehicle cost and throughput
  • Improved serviceability in the field and ability to retrofit into existing applications
  • Interior locking mechanism provides additional safety for occupants
  • Single motion egress

System kits are available and include power lock actuators and electronic accessories including custom wiring harnesses, relays, switches, door contacts, actuators and mounting hardware to provide a comprehensive electro-mechanical access solution.


500-1300 e-ASK PKE System (Passive Keyless Entry)

The 500-1300 System is TriMark's Next Generation of e-ASK. This comprehensive matched system allows for complete keyless entry, security, and ignition control for varied levels of sophistication of on- or off-highway vehicles. Additional features include:

  • Passive Keyless Entry (PKE) provides for "hands free" unlocking
  • Provides advanced electronic interface for the ultimate in end user convenience, functionality and security
  • Offers optional vehicle mobilization/immobilization and keyless push button start
  • Software adaptations can be provided for specific OEM and customer requirements

These are the same 'state of the art' electronics that are featured on high end automobiles and is now available for integration on your vehicles.


590-1100 Emergency Exit Window Latch and Interlock Switch

This sliding bolt security latch/switch is FMVSS 217 compliant for bus window emergency exits. It contains an integrated switch that is designed to actuate an audible signal to the driver when the slide latch is locked and the vehicle's ignition is in the on position. Other product details include:

  • Self-contained assembly is easy to install and connect
  • Assembly is provided with a ball detent to hold the slide bolt in the locked and unlocked position
  • Bolt extension is 1.0 in. (25.4mm)

System kits are available and include handles, latches, power lock actuators and electronic accessories including custom wiring harnesses, relays, switches, door contacts, actuators, mounting hardware, sirens and lighting to provide a comprehensive electro-mechanical access solution.


550-0100 Compact Style Power Lock Actuator

TriMark's new Power Lock Actuator features a patent pending clutch mechanism for soft starts/stops and also allows for manual override with a key. It's 'best in class' performance has been tested and validated to meet stringent requirements thus ensuring a long life of trouble free operation. Other product details include:

  • Reliable and durable to high cycle counts in various environmental extremes
  • Standard case configuration, so this product retrofits to other common compact style actuators
  • Motor is equipped with 12V thermal protection to prevent motor failing due to excessive heating from extreme usage such as rapid, frequent operations or sustained activation
  • Standard motor varistor for transient emission protection (electromagnetic interference) to limit electrical spikes associated to environmental interference
  • Multiple wiring options available with possible customization including special connectors and custom wire lengths.

System kits are available and include handles, latches, accessories and keyless entry e-ASK systems to provide a comprehensive electro-mechanical access solution.


050-0700 12mm Single Rotor Latch

This compact single rotor latch is designed for use on light to medium duty operator and compartment doors for on or off-highway applications. The single rotor latch offers robust construction and compact size for a very cost effective price. Other product details include:

  • Versions are available to allow direct or remote actuation with TriMark's exterior handles and interior release for application flexibility
  • Dual position rotary latching function for use with 12mm diameter striker
  • Standard black finish reduces the need for secondary painting or covers

System kits are available and include handles, latches and accessories to provide a comprehensive access solution.






050-0810 Single Rotor Latch Logic

The new 050-0810 Single Rotor Latch/Logic system is intended for occupant or exit/entry doors for specialty vehicles including ambulance, fire/rescue and off-highway vehicles (light duty) that require compliance to FMVSS 206 standards. The flexible design allows for internal or external door mounting and provides automotive logic function with remote activating handles. Other product benefits include:

  • Free floating external paddle when locked
  • Compatible for the addition of power actuation and keyless entry
  • Overrides locking function with internal handle actuation
  • Prevents inadvertent lockouts

Other components are available and include handles, latches, rods, brackets and powerlock actuators to provide a comprehensive electro-mechanical access solution and comply with FMVSS 206 requirements.


110-0403 Cam Lock

Designed as a simple companion for TriMark's locking solutions, these 1/4 turn cam locks feature KeyOne Plus keying, multiple body lengths and a variety of cam options to provide application flexibility. Other product details include:

  • The KeyOne Plus locking system allows the operation of multiple onboard locking hardware with a single key or the option to key differently
  • Easy to install, mounting nut and cam mount screw included

System kits are available and include handles, latches and accessories to provide a comprehensive access solution.


©2018 TriMark Corporation. All rights reserved.     Privacy  •  Legal Info  •  Terms and Conditions of Sale
